Advanced Tow Assist activation

Technical Overview

Advanced Tow Assist relies on network‑wide cooperation between TBCM tow‑bar‑control‑module, surround‑camera ECU, PSCM electric‑power‑steering, DSC stability‑control, ATCM terrain‑control‑module and infotainment IMC unit. Camera‑captured hitch‑articulation‑angle data feeds kinematic trajectory‑calculations; when the driver turns the Terrain‑Response 2 rotary‑controller, the system calculates required steering‑wheel movement and sends actuation requests to PSCM, while overlaying current‑and‑desired‑trajectory guidance lines onto the infotainment surround‑camera view. Feature‑enablement requires coordinated CCF edits across chassis‑towing‑domain flags, camera‑system parameters and infotainment‑HMI entries to render towing‑assist menus and on‑screen trajectory overlays. This coding workflow reads and backs‑up original factory CCF dataset, enables Advanced‑Tow‑Assist fitment‑flags, executes cross‑module integrity validation and writes modified configuration via OBD‑II connection. Post‑write, controlled TBCM‑camera‑ECU resets plus full‑vehicle sleep‑wake cycle are mandatory for full feature‑initialisation. This is purely software‑based activation; all physical towing‑related hardware must already be factory‑installed. Full roll‑back to factory‑spec can be achieved restoring backed‑up original CCF file.

Core Technical Activation Capabilities

• Multi‑block chassis‑TBCM‑CCF‑parameter modification unlocking Advanced Tow Assist for towing‑hardware‑equipped JLR vehicles
• Enables rotary‑dial‑controlled trailer‑reverse‑steering assist, infotainment‑camera trajectory‑overlay graphics and towing‑assist HMI menu entries
• Pre‑write cross‑module CCF integrity validation preventing incompatible TBCM‑camera‑PSCM‑ATCM parameter combinations before committing changes to vehicle ECUs
• Complete CCF backup‑restore workflow preserving original factory‑configuration before applying towing‑chassis‑domain‑related changes
• Chassis‑towing diagnostic routines: read TBCM, surround‑camera‑ECU, PSCM and DSC DTC faults; verify pre‑activation and post‑activation Advanced‑Tow‑Assist feature‑flag‑status
• Session‑log generation capturing vehicle VIN, timestamp and modified chassis‑towing‑CCF parameters for internal workshop audit‑trail purposes.

Vehicle, Hardware & System Prerequisites

Critical hardware prerequisites: vehicle must have factory‑fitted TBCM tow‑bar‑control‑module, valid tow‑bar assembly with 13‑pin towing electrics, full Surround‑Camera‑System and Terrain‑Response 2 rotary‑controller hardware. Advanced Tow Assist cannot be enabled‑by‑coding‑alone if any required towing‑camera‑chassis‑components are missing or faulty. Supported MY2017‑2025 Range‑Rover, Range‑Rover‑Sport, Defender and Discovery model‑lines. Host‑system requirement: Windows 10 / Windows 11 64‑bit PC with valid SX‑TOOL software licence. Use J2534 pass‑through adapters for older CAN‑bus vehicles or Enet‑WiFi / Type‑C Enet‑cable hardware for DoIP‑platform vehicles. Stable regulated 12 V battery supply is mandatory for CCF‑write cycles and module resets. Some late‑model secure‑gateway‑protected vehicles may require supplementary online authorisation for chassis‑domain‑configuration‑writes. Important note: Advanced Tow Assist is a driver‑aid; driver remains fully responsible for safe trailer‑reversing and observing local towing‑regulations.

What This Activation Service Includes

• Advanced Tow Assist multi‑block TBCM‑chassis CCF‑coding‑activation workflow for towing‑hardware‑qualified‑compatible‑JLR‑vehicles
• Chassis‑towing‑domain CCF backup‑restore tool‑set for Advanced‑Tow‑Assist‑related‑configuration‑datasets
• Technical documentation: pre‑activation‑hardware‑verification‑checklist, coding‑procedure and post‑activation‑towing‑function‑testing‑guidance‑including‑vehicle‑sleep‑cycle‑instructions
